Three phase AC380V ± 10% /, 50Hz ~ 60Hz
Current stabilizing accuracy
Voltage stabilizing accuracy
Forced air cooling
48 hour operation at full load
Safety regulations and standards
Comply with EU CE standards: 2006 / 95 / EC, 2004 / 108 / CE
IP protection class
● adopt new four channel IGBT technical structure.
● improve the reliability of electroplating production and operation:
The rectifier is designed in n 1 mode. Under normal conditions, all modules participate in the work. If the equipment fails, the power supply will not stop, and the system will automatically reduce the current operation and exit the failed unit, which will not affect the production.
● maintenance is convenient and all module units are universal. Only a few module units need to be backed up to freely replace the faulty module, making maintenance relatively simple and fast.
● network digital control system, each module unit takes microprocessor as the control core, and mainly adopts software program to realize automatic current sharing and other control schemes, with flexible control, high precision, fast current response and high reliability.
● the main control circuit board adopts advanced sealing design imported from Japan, which is acid and alkali resistant and can be directly placed in every corner of the electroplating tank.
● the whole power supply system adopts intelligent main line structure to realize module hot plug, current sharing control, fault detection and fault information display, and the user control interface is simple and convenient.
eight hundred and forty
one thousand and four hundred
0 ~ 24V
Operating system: remote control
